Siemens W0408ML1125 Single-Phase Outdoor EQ Loadcenter, 125A, 4 Spaces/8 Circuits ML, 120/240 VAC, 2-Pole, NEMA 3R

Product Description

The Siemens W0408ML1125 is a single-phase outdoor load center designed for residential and commercial use. This load center operates at one hundred twenty to two hundred forty volts and provides a maximum of one hundred twenty-five amperes. It features four spaces and eight circuits, making it suitable for various electrical configurations.

• Constructed for wet and dry locations
• Includes two factory-installed ground bars
• Rated for two poles and NEMA 3R enclosure

Product Highlights

Product Information

Standard Information

• Brand: Siemens Industry
• Manufacturer: Siemens Industry

Technical Specifications

• UPC: 783643123892
• Type: Circuit Breakers Enclosures
• Depth: 4.25 inches
• Width: 6 inches
• Height: 12.25 inches
• Weight: 6.81 pounds
• NEMA Rating: NEMA 3R
• Voltage Rating: 120/240 VAC
• Amperage Rating: 125 Amperes
• Number Of Poles: 2-Pole
• Frequency Rating: 50/60 Hertz
• Interrupt Rating: 100 kAIC
• Country of Origin: MX
• Environmental Conditions: Wet/Dry Location
