Siemens TL2F77RB Temp Power Surface Mount Bottom Feed Metered 125A Main Lug Outlet Panel

Product Description

The Siemens TL2F77RB is a Temp Power Surface Mount Bottom Feed Metered 125A Main Lug Outlet Panel designed for reliable temporary power distribution. It features one 14-30R 30A GFCI 125/250V outlet and two 5-20R2GFI 125V 20A GFCI outlets, making it ideal for various temporary power needs.

• Rainproof NEMA Type 3R construction
• Utility grade, meter socket base
• Effortless installation with three raised mounting embosses

Product Highlights

This panel is suited for underground feeds and has easily removable deadfronts for maintenance. It offers padlock provisions to prevent unauthorized access, ensuring safety on job sites.

Product Information

Standard Information

• Brand: Siemens
• Part Number: TL2F77RB

Technical Specifications

• Amperage: 125 A
• Enclosure Type: Bottom Feed Metered
• Meter/Bypass: Ringless, No Bypass
• Mounting: Surface
• Number of Receptacles: 3
• Receptacles: (1) 14-30R 30A GFCI 125/250V, (2) 5-20R2GFI 125V 20A GFCI
• Type: Main Lug
