Siemens TL277RP Low Voltage Ringless Metered Power Outlet Panel 125/250 VAC 125 A 1 Phase 350 kcmil Wire

Product Description

The Siemens TL277RP is a low voltage ringless metered power outlet panel with a voltage rating of one hundred twenty-five/ two hundred fifty VOLT AC and an amperage rating of one hundred twenty-five A. This panel is designed for use in temporary power applications and can accommodate up to one phase.

• Durable stainless steel latch and hasp
• Easy access with a user-friendly receptacle cover
• Adaptable to various configurations for efficient installation

Product Highlights

The TL277RP is built for reliability in challenging environments, featuring a NEMA three R enclosure that provides protection against the elements.

Product Information

Standard Information

• Brand: Siemens
• MPN: TL277RP

Technical Specifications

• Amperage Rating: 125 A
• Application: Temporary Power Applications
• Connection Type: Main Lug
• Country of Origin: US
• Enclosure Type: NEMA 3R
• Feed Type: Loop/Overhead
• Material: Galvanized Steel
• Mfg Standards/Approvals: ARRA, Buy American Act, RoHS Compliant, UL 231, UL 67, UL 414, UL 50
• Mounting Type: Direct Burial Pedestal
• Package Height: 9.2 inches
• Package Length: 73.5 inches
• Package Weight: 51.0 lb
• Package Width: 9.9 inches
• Phase: 1
• Receptacle Type: 14-30R/5-20R2GFI
• Series: TL Series
• Type: Low Voltage Ringless
• Voltage Rating: 125/250 VAC
• Wire Size: 350 kcmil
