Siemens SQM50.264R1K3 Actuator 110 V (90°)

Product Description

Siemens SQM50.264R1K3 is a SQM5-series modulating actuator rated at 90 in-lb torque with a 110 V supply. It provides 90-degree rotation via a 3/8" output shaft and an 8-second running time, receiving 0-10 VDC control signals for proportional positioning. Exchangeable circuit boards enable zero/span adjustment, parallel or master/slave operation, split-range control and input-signal override. Internal switches, an auto/manual selector and an external shaft position indicator assist setup and diagnostics.

• 90 in-lb torque, 8 second running time, 110 V supply, 0-10 VDC control input
• 90-degree rotation with 3/8" output shaft; externally visible shaft position indicator
• Exchangeable circuit boards for zero/span adjustment, master/slave, split range and input override; six internal switches and auto/manual selector

Product Highlights

SQM5-series modulating actuator; 90 in-lb torque; 8 s runtime; 110 V supply; 0-10 VDC control; exchangeable electronics and external position indicator.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: SQM50.264R1K3
