Siemens SN1632L1125 Single-Phase Low Voltage Plug-On Load Center, Main Lug, 125A, 16 Spaces/32 Circuits, Replacement MPN

Product Description

The Siemens SN1632L1125 is a single-phase low voltage plug-on load center. It is designed to handle a main lug setup for efficient electrical distribution. This load center includes sixteen one-inch spaces and allows for a maximum of thirty-two circuits. The unit is rated for 125 amperes and operates at a voltage of 120/240 VAC. Its aluminum bus ensures durability, while the NEMA Type 1 enclosure makes it suitable for indoor settings.

• Single-phase 3-wire system
• 100kAIC interrupt rating
• Compliant with UL standards

Product Highlights

This load center provides a reliable solution for power distribution in residential applications.

Product Information

Standard Information

• Brand: Siemens Industry
• Manufacturer: Siemens Industry

Technical Specifications

• MPN: SN1632L1125
• UPC: 804766703256
• Type: Load Centers
• Depth: 4.33 inches
• Width: 15.74 inches
• Height: 22.83 inches
• Weight: 24.47 pounds
• Phase: Single-Phase
• Mounting: Surface
• NEMA Rating: NEMA 1
• Voltage Rating: 120/240 VAC
• Amperage Rating: 125 Amperes
• Interrupt Rating: 100 kAIC
• Number Of Spaces: 16
• Wiring Configuration: 3-Wire
• Country of Origin: MX
