Siemens SC250C 2-Position Gangable Low Voltage Residential Unbussed Meter Socket 300 VAC 80 A

Product Description

The Siemens SC250C meter socket is a 2-position gangable, low voltage residential unbussed socket, designed with quality and durability in mind. Rated at 300 VAC and 80 A, this meter socket is suitable for residential applications. It features a NEMA 3R enclosure for environmental protection.

• 6 to 4/0 AWG line lug
• 8 to 2/0 AWG load lug
• Without bypass

Product Highlights

This Siemens meter socket is built to last, offering reliable performance for residential metering installations. Meets UL standards.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: SC250C
• Country of Origin: USA

Technical Specifications

• Phase: 1
• UNSPSC: 39121102
• Hub Size: 1-1/4
• Wire Size: 8 to 2/0 AWG, 6 to 4/0 AWG
• Application: Residential Applications
• Terminal Type: Line/Load Lug
• Enclosure Type: NEMA 3R
• Voltage Rating: 300 Volt
• Type: METER MOUNTING
• Hub Type: Top Knockout
• Cover Type: Ring
• Amperage Rating: 80 Amp
• Cable Entry: RESIDENTIALENDFEED
• Enclosure: RING
• Insulated?: Yes
• Number of Phases: 1 Phase
• Manufacturer: SIEMENS
