Siemens S15JLD6 Breaker JD/LD/LMD 277VA

Product Description

The Siemens S15JLD6 is a low voltage Sentron molded case circuit breaker internal accessory. This 277VAC shunt trip is designed to suit JD, LD, and LMD frame breakers. It provides remote tripping capability for enhanced control and safety in electrical systems.

• Low voltage
• Molded case
• Internal accessory
• 277VAC shunt trip
• Suits JD / LD / LMD frame breakers

Product Highlights

The Siemens S15JLD6 shunt trip is engineered for integration into low voltage power distribution applications, supporting reliable and precise circuit interruption when activated.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: S15JLD6
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: S15JLD6
• Brand: Siemens
• Manufacturer: Siemens
• Frame: JD/LD/LMD
• Width: 5.000
• Height: 4 Inch
• Length: 5
• Voltage: 277 Volt
• Actuator: 1 SHUNT TRIP
• Standard: UL
• Sub Brand: Sentron
• Type: Shunt Trip
• Mounting Type: Right Pole
• Voltage Rating: 277
• Connection Type: Wire Leads
• Suitable For Use With: JD, LD, LMD Frame Circuit Breaker
• Part Number: S15JLD6
• Category: Circuit Breaker
• Item Subcategory: Shunt Trip
• Family: Sentron Series
• Control Voltage Minimum: 277
• Compatible Frames: JD,LD,LMD,HJD,HLD,HLMD,HHJD,HHLD,JXD,LXD,LMXD,HJXD,HLXD,HLMXD,HHJXD,HHLXD,CJD,CLD,SLD,SJD,SHLD,SHJD,SCLD,SCJD,JM6B,JMKB,LM6B,LMKB
• Control Voltate Maximum: 277
• Volts AC: 277VAC
• Mounting Location - Pole: Right
