Siemens QAE2112.010 Immersion temperature sensor Pt1000 (100 mm)

Product Description

Siemens QAE2112.010 is an immersion temperature sensor with a Pt1000 sensing element and a 100 mm probe intended for HVAC, industrial, and building automation temperature measurement. It measures -30 to 130 °C with an accuracy of ±0.95 K (at -30 to 130 °C). The sensor has a time constant of 8 s without a protection pocket and 30 s with a protection pocket, and uses screw terminal electrical connections with a G 1/2" thread.

• Pt1000 sensing element, measuring range -30 to 130 °C, accuracy ±0.95 K
• 100 mm stainless steel immersion probe; protection pocket not included
• Screw terminal electrical connection, connecting thread G 1/2", time constant 8 s without pocket

Product Highlights

Immersion Pt1000 sensor, 100 mm probe, -30 to 130 °C range, ±0.95 K accuracy, no protection pocket included

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: QAE2112.010

Technical Specifications

• Brand: Siemens
• MPN: QAE2112.010
• Sensing element: Pt1000
• Output signal: PT1000
• Measured value: Temperature
• Measuring range: -30 to 130 °C
• Measurement accuracy: ±0.95 K (at -30 to 130 °C)
• Immersion length: 100 mm
• Time constant: 30 s (with protection pocket); 8 s (without protection pocket)
• Protection pocket: Not included (can be added as accessory)
• Material (immersion pocket): Stainless steel
• Connection (electrical): Screw terminals
• Connecting thread: G 1/2"
• Display: No display
• Installation: Immersion
• Body material: Stainless steel
• Dimensions (W x H x D): 80 x 60 x 31 mm (3.15 x 2.36 x 1.22 inches)
• Fixing: By protection pocket or compression fitting
• Nominal pressure (with compression fitting AQE2102): 16 bar (PN16)
• GTIN: 7612914073471
