Product Description
The Siemens Q120DF is a dual function circuit breaker designed for specific residential electrical needs. With model number Q120DF, this device combines arc fault protection (AFCI) and ground fault protection (GFCI) into one unit. The device is rated for twenty Amps and operates at one hundred twenty Volts, capable of interrupting a fault current of up to ten kiloamperes.
- Combines AFCI and GFCI protection.
- Plug-on installation makes setup easy.
- Ideal for kitchen and laundry circuit compliance.
Product Highlights
This circuit breaker is suitable for a variety of applications including personal, parallel, and series arcing protection. It adheres to the 2014 National Electrical Code (NEC) requirements for enhanced safety in residential settings.
Product Information
Standard Information
-
Brand: Siemens
-
MPN: Q120DF
Technical Specifications
-
Voltage Rating: 120 Volt
-
Amperage Rating: 20 Amp
-
Connection Type: Plug-On
-
Number of Poles: 1 Pole
-
Interrupt Rating: 10 kAIC
-
Dimensions: 1.35 in (W) x 4.35 in (L) x 3.2 in (H)
-
Country of Origin: Philippines
-
Standard Approvals: UL 1699, UL 943
