Siemens PNW0816B1200TC Load Center Breaker Main 120/240VAC 200A 16

Product Description

Siemens PNW0816B1200TC is a main breaker load center designed for single-phase applications. It operates at 120/240VAC with an amperage rating of 200A. The load center has eight spaces, allowing for a maximum of sixteen circuits.

• Features copper bus bars and feed-thru lugs.
• Constructed with a NEMA 3R enclosure, suitable for outdoor use.
• Includes plug-on neutral ready features for quicker installations.

Product Highlights

This load center meets the needs of residential and light commercial electric distribution. The design helps contractors by providing time-saving features during installation, enhancing overall flexibility.

Product Information

Standard Information

• Manufacturer: Siemens
• MPN: PNW0816B1200TC

Technical Specifications

• Type: 1-Phase Assembled Convertible Low Voltage
• Voltage Rating: 120/240 VAC
• Amperage Rating: 200 A
• Interrupt Rating: 22 kAIC
• Number of Spaces: 8
• Number of Circuits: 16
• Wiring Configuration: 3-Wire
• Enclosure Type: NEMA 3R
• Enclosure Box Size: 14-1/2 in W x 4-1/2 in D x 23 in H
