Siemens P1A54MC400AT RP1 UPB 1P3W 400A

Product Description

Siemens P1A54MC400AT is a reliable panelboard interior designed for efficient power distribution. It supports a voltage rating of one hundred twenty to two hundred forty volts and can handle a maximum current of four hundred amps. This model is compatible with Next Gen P1 panelboards and is suitable for lighting loads and branch circuit loads.

• Amperage rating: four hundred amps
• Dimensions: seventy-four inches high, twenty inches wide, and five and three-fourths inches deep
• Configured for one phase and three wire use

Product Highlights

This product's symmetrical interior allows for easy changes between top and bottom feed just by rotating the interior.

Product Information

Standard Information

• Manufacturer: Siemens
• Country of Origin: USA

Technical Specifications

• MPN: P1A54MC400AT
• Catalog Number: P1A54MC400AT
• Type: Type P1
• Material: Steel
• Bus Material: Aluminum
• Phase: 1
• Number of Poles: 54
• Weight: 36 lbs
• Applications: Lighting Loads/Branch Circuit Loads
