Siemens MT0500J Class MT Control Power Transformer 240/480 VAC Primary 25/120 VAC Secondary 500 VA Power Rating

Product Description

The Siemens MT0500J is a Class MT Control Power Transformer designed for reliability and efficiency. This transformer features a primary voltage of 240/480 VAC and a secondary voltage of 25/120 VAC, supplying a power rating of 500 VA. It operates at frequencies of 50/60 Hz and is suitable for one-phase installations.

• Robust and compact design, ideal for domestic usage.
• Includes integral fuse clips to save wiring time and cost.
• Provides maximum protection against moisture and industrial contaminants.

Product Highlights

This transformer is designed for industrial and domestic applications, providing insulation and sealing that protects against environmental factors.

Product Information

Standard Information

• Brand: Siemens
• Manufacturer: Siemens

Technical Specifications

• Power Rating: 500 VA
• Primary Voltage: 240/480 VAC
• Secondary Voltage: 25/120 VAC
• Frequency Rating: 50/60 Hz
• Phase: 1
• Maximum Amperage Rating: 0.29 A
• Dimensions: 5.69 in H x 5.25 in W x 6.67 in D
• Insulation: Epoxy
• Mounting Type: Slotted
• Connection Type: Screw
• Enclosure Type: IP20
• Standard & Approvals: cUL Listed, UL Listed, CSA Certified, ANSI Specified
