Siemens MC4040B1200SECW 120/240 VAC 200 Amp 1-Phase 3-Wire NEMA 3R Ring Type Combination Meter Load Center

Product Description

The Siemens MC4040B1200SECW is a meter load center designed for efficient electrical management. It operates on 120/240 volts with a capacity of 200 amps. This product features a ring-type cover and is suited for service entrance applications. It has factory-installed main breakers and allows up to forty circuits with its spacious interior. The design supports surface mounting, making installation straightforward.

• Rated for 200 amps and 120/240 volts.
• Compatible with both overhead and underground feed configurations.
• Surface mounting for easy installation.

Product Highlights

This load center is ideal for single-phase electrical systems, featuring a four-jaw meter suitable for various applications.

Product Information

Standard Information

• Brand: Siemens
• Model: MC4040B1200SECW

Technical Specifications

• Amperage Rating: 200 Amp
• Voltage Rating: 120/240 Volt
• Phases: 1 Phase
• Size: 1
• Enclosure Type: Ring
• Cable Entry: Top/Bottom
• Mounting Type: Surface
• Country of Origin: Mexico
• Weight: 54.200 lb
• Dimensions: 33.8 x 22.6 x 5.8 inches
