Siemens HQR23B125 Qr molded case circuit breaker 65 kA 240 V 3P 125 A

Product Description

Siemens HQR23B125 is a QR molded case circuit breaker rated 125 A at 240 V with a 65 kA interrupting rating. It is a three-pole thermal-magnetic breaker designed for low-voltage circuit protection, featuring load lug (TC) connections and a 40 degrees C ambient temperature rating. Dimensions are approximately 4.5 in W x 3.39 in D x 7 in H and approvals include UL 489 and CSA C22.2.

• Three-pole thermal-magnetic breaker, 125 A at 240 V AC (50/60 Hz)
• 65 kA interrupting rating at 240 V; QR molded case frame
• Load lug (TC) terminals, 40 degrees C ambient rating; UL 489 and CSA C22.2 approvals

Product Highlights

Three-pole 125 A QR molded case breaker with 65 kA interrupting capacity for low-voltage circuit protection.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: HQR23B125
• Country of Origin: Mexico

Technical Specifications

• MPN: HQR23B125
• Brand: Siemens
• Product Type: Molded case circuit breaker (thermal-magnetic)
• Frame Type: QR
• Poles: 3
• Current Rating: 125 A (at 40 degrees C)
• Voltage Rating: 240 V AC (50/60 Hz)
• Interrupting Rating: 65 kA at 240 V AC
• Trip Type: Thermal-magnetic
• Terminal Type: Load lugs (TC)
• Temperature Rating: 40 degrees C ambient
• Dimensions: 4.5 in W x 3.39 in D x 7 in H
• Width: 4.5 in
• Depth: 3.39 in
• Height: 7 in
• Approvals: UL 489; CSA C22.2
• Application: General purpose, low-voltage circuit protection
• Country Of Origin: MEX
• UPC: 804766136917
• GTIN / EAN: 0804766136917
