Siemens HNF261S 600 VAC 30 Amp 2-Pole 2-Wire NEMA 4X Heavy Duty Non-Fusible Safety Switch

Product Description

The Siemens HNF261S is a low voltage circuit protection heavy-duty safety switch. This 2-pole non-fused switch is housed in a type 4/4X 304 grade stainless steel enclosure and is rated for 600VAC at 30A. It is suitable as a disconnecting means for service entrance or loads.

• 2-Pole Non-Fused
• Type 4/4X 304 grade Stainless Steel enclosure
• Rated 600VAC (30A)

Product Highlights

The Siemens HNF261S safety switch offers reliable circuit protection in demanding environments. Its heavy-duty construction and NEMA 4X enclosure ensure durability and safety.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: HNF261S
• Country of Origin: Mexico

Technical Specifications

• Type: HEAVYDUTYSWITCH
• Brand: Siemens
• Width: 11.900 in
• Action: SINGLE THROW
• Height: 8.1 Inch
• Length: 16.9 Inch
• Voltage: 600 Volt
• Amperage: 30 Amp
• Material: Stainless Steel
• Enclosure: NEMA4X
• Frequency: 60 Hz
• Sub Brand: VBII
• Insulated?: Yes
• Applications: DISCONNECTINGMEANFORSERVICEENTRANCE/LOADS
• Mounting Type: SURFACE
• TC Connection: MECHANICALLUGS
• Connection Type: MECHANICAL LUGS
• Number of Poles: 2 Pole
• MPN: HNF261S
• Poles: 2-Pole
• Wiring: 2-Wire
