Siemens HF364NR 480/600 VAC/250/600 VDC 200 Amp 3-Pole 4-Wire NEMA 3R Heavy Duty Fusible Safety Switch

Product Description

Siemens HF364NR is a heavy duty fusible safety switch designed for low voltage circuit protection. This switch operates at 480/600 VAC and 250/600 VDC. It features a solid neutral design and is housed in a NEMA 3R rated enclosure, making it suitable for outdoor use. The 200 Amp capacity ensures robust performance in various applications. The construction is designed to handle demanding environments and ensure safety during operation.

• Type 3R enclosure suitable for outdoor applications.
• Rated for up to 200 Amps.
• Compatible with Class R or J fuses.

Product Highlights

Siemens HF364NR provides reliable operation with visual blade construction and quick-make, quick-break mechanisms that enhance safety and ease of use.

Product Information

Standard Information

• Brand: Siemens
• MPN: HF364NR

Technical Specifications

• Voltage: 480/600 VAC, 250/600 VDC
• Amperage: 200 Amp
• Number of Poles: 3
• Number of Wires: 4
• Enclosure: NEMA 3R
• Height: 10.2 inches
• Width: 18.9 inches
• Length: 33.9 inches
• Weight: 42.8 lbs
