Siemens HF224NR SWITCH SAF 240VAC 200A 15HP DPST

Product Description

Siemens HF224NR is a heavy-duty safety switch designed for low voltage applications. This model operates at 240 VAC and has a capacity of 200 amperes with a horsepower rating of 15. It features a Double-Pole Single-Throw (DPST) contact form and is suitable for surface mounting in outdoor conditions.

• Quick-make, quick break mechanism for positive operation.
• Durable NEMA 3R enclosure for outdoor use.
• Spring reinforced fuse clips for reliable contact.

Product Highlights

The Siemens HF224NR provides safe and effective power disconnection with quick access for maintenance. Its sturdy construction minimizes environmental hazards while ensuring operational reliability.

Product Information

Standard Information

• Brand: Siemens
• MPN: HF224NR

Technical Specifications

• Voltage Rating: 240 VAC
• Amperage Rating: 200 A
• Horsepower: 15 hp
• Contact Form: DPST
• Number of Poles: 2
• Enclosure Type: NEMA 3R
• Dimensions: 29.9 in H x 15.94 in W x 12.33 in D
• Material: Steel
• Temperature Rating: -29 to 85 deg C
• Frequency Rating: 60 Hz
