Siemens HEG3B050L BRKR HEG 50A 3P 480V

Product Description

The Siemens HEG3B050L is a low voltage EG frame circuit breaker with thermal-magnetic trip. This UL listed HEG frame features high breaking capacity. Rated at 50A, 3-pole, it offers 25kAIC at 600Y/347V and 65kAIC at 480V. It mounts on DIN rail or screw and includes line and load side lugs (TA1EG10).

• LOW VOLTAGE EG FRAME
• THERMAL - MAGNETIC TRIP
• UL LISTED HEG FRAME WITH HIGH BREAKING CAPACITY

Product Highlights

This Siemens circuit breaker is designed for reliable power distribution in commercial and industrial applications.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: HEG3B050L
• Country of Origin: Dominican Republic

Technical Specifications

• Type: HEG
• Brand: Siemens
• Frame: 125A
• Voltage: 600 Volt
• Amperage: 50 Amp
• Standard: UL,IEC,CSA,NOM
• Frequency: 50/60 Hz
• Trip Type: THERMAL MAGNETIC TRIP UNIT
• Number of Poles: 3 Pole
• Interrupt Rating: 25 kAIC
• Category: Circuit Breaker
• Item Subcategory: Molded Case
• Family: VL Series
• Phase: 3
• AIC rating: 65kA@480V
• Connection: Feed-Thru
• Functions: LI - Long-Time and Instantaneous
• Protection: Thermal Magnetic
• Wire Size: AWS 8 to AWS 1/0, Cu/Al
• TC Connection: LOAD END STANDARD CU/AL LUGS
• Connection Type: Load End Standard (CU/AL) Lugs
• Applications: GLOBAL INTERCHANGEABLE
