Siemens HED43B015L Molded Case Circuit Breaker 15 Amp 480 VAC

Product Description

The SIEMENS HED43B015L is a 3-pole molded case circuit breaker with a thermal-magnetic trip unit. This standard 40C breaker features an ED frame with high breaking capacity. Rated at 15A and 480V, it provides reliable circuit protection in industrial applications. Includes line and load side lugs (SA1E025) with a wire range of 14 - 10AWG (CU) / 12 - 10AWG (AL).

• Thermal-magnetic trip unit
• Standard 40C breaker ED frame with high breaking capacity
• Non-interchangeable trip unit

Product Highlights

Molded case circuit breaker with thermal-magnetic trip, ED frame, and line/load lugs for robust circuit protection.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: HED43B015L
• Country of Origin: Mexico

Technical Specifications

• Type: HED4
• Brand: Siemens
• Frame: ED
• Width: 7.000
• Height: 4
• Length: 6
• Voltage: 480
• Amperage: 15 Amp
• Standard: HACR
• Frequency: 50/60 Hz
• Sub Brand: Sentron
• Trip Type: Thermal-Magnetic
• Number of Poles: 3 Pole
• Interrupt Rating: 42 kAIC
• Operating Temperature: 40C
• Part Number: HED43B015L
• Manufacturer: Siemens
• Category: Circuit Breaker
• Item Subcategory: Molded Case
• Family: Sentron Series
• Phase: 3
• AIC rating: 42kA@480V
• Connection: Feed-Thru
• Functions: LI - Long-Time and Instantaneous
• Frame Size: ED Frame
• Protection: Thermal Magnetic
• Certification: Ul Listed
