Siemens GQD126.1P Direct Coupled Actuator 20 in-lb 24v S/R 2-AuxSw

Product Description

The Siemens GQD126.1P is a direct coupled actuator designed for two-position control applications. This actuator operates on twenty-four volts alternating current or direct current and offers a torque of twenty in-pounds. It is suitable for various HVAC control systems, enabling precise control over dampers and valves.

• Spring return mechanism ensures a fail-safe operation.
• Pre-cabled installation simplifies setup and reduces wiring time.
• UL listed and CE certified, suitable for installation in plenum areas.

Product Highlights

This reliable actuator features a compact design, ideal for installations with limited space. It operates efficiently in a temperature range of minus twenty-five degrees Fahrenheit to one hundred thirty degrees Fahrenheit and supports dual auxiliary switches for added functionality.

Product Information

Standard Information

• Brand: Siemens Building Technology
• Part Number: GQD126.1P

Technical Specifications

• Housing: NEMA 1
• Power Consumption: 6.5 VA Running, 4 VA Holding
• Operating Conditions: -25 F to 130 F (-32 C to 55 C)
• Electrical Connection: 3 ft. 18 AWG Plenum Cable
• Auxiliary Switches: Dual
