Siemens GPC121.1P Openair Damper Actuator, Sr Rotary, 35 Lb-in

Product Description

The Siemens GPC121.1P is an Openair damper actuator with spring return and 35 lb-in torque. It is designed for use on economizer dampers and small control dampers. It operates on 24 VAC/DC and is plenum rated.

• 35 lb-in torque
• 24 VAC/DC
• Plenum rated

Product Highlights

The Siemens GPC121.1P damper actuator is ideal for controlling economizer and small dampers.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: GPC121.1P

Technical Specifications

• Brand: Siemens Industry
• MPN: GPC121.1P
• SKU: GPC121.1P
• Actuator Type: Electronic spring return
• Control Input: Modulating
• End Switch: Yes
• Spring Return: Spring Return
• Type: Damper Actuator
• Voltage: 24 VAC
• Max Temp: 130 0F
• NSR/SR Actuator: Spring Return
• Fail Safe: Y
• Control Signal Type: 2-position
• Nominal Voltage: 24 VAC/DC
• NEMA Rating: NEMA 1, Plenum rated rugged plastic
• Aux Switches: 0
• Damper Actuator Torque: 35 lb-in
• Plenum Rating: Plenum
• Damper Actuation Application: Control Damper
• Cable Length: 3 ft
• Damper Actuation Style: Rotary
• Operating voltage: 24 VAC;24 VDC
• Watts: 1.6
• VA Rating: 2.6
• Stroke Degrees: 90 0
• Power Consumption: Running: 3.4 VA (2.0 W), Holding: 2.6 VA (1.6 W)
• Indoor/Outdoor: Indoor
