SIEMENS GPC121.1P Damper Actuator, Spring Return, 35 lb-in, 2-Position Control, 24VAC/DC Plenum Rated

The Siemens GPC121.1P Damper Actuator is a direct coupled damper actuator with brushless motor technology and a rugged, lightweight housing. It features a spring return, 35 lb-in, 2-position control, and 24VAC/DC plenum rated for use on economizer dampers and small control dampers.

• Spring return
• 35 lb-in 2-position control
• 24VAC/DC plenum rated
• For use on economizer dampers and small control dampers

Specifications:

• Torque: 35 lb-in
• Actuator Type: Spring return
• Actuation Style: Rotary
• Fail Safe: Yes
• Control Signal: 2-Position
• Positioning time: Runtime for 90 60 s
• Position feedback: No
• Power consumption: Running: 3.4 VA (2.0 W), Holding: 2.6 VA (1.6 W)
• Ambient temperature, operation: -25 to 130 F, -32 to 55 C
• Angular rotation: 90
• Supply Voltage: 24 VAC/DC
• Auxiliary Switch: None
• Cable length: 3 ft
• Dimensions (W x H x D): 2.83 x 5.61 x 2.48 in
• Material, housing: Plenum rated rugged plastic
• Ingress Protection: NEMA 1
