Siemens GNF321 240 VAC/250 VDC 30 Amp 3-Pole NEMA 1 General Duty Non-Fusible Safety Switch

Product Description

The Siemens GNF321 is a 240 VAC/250 VDC 30 Amp 3-Pole NEMA 1 general duty non-fusible safety switch. Suitable for 3-PH motor loads, it serves as a disconnecting means for service entrance/loads. Constructed of steel, it features 2 or 3 point mounting holes and is UL standard compliant.

• Rated for 240 VAC and 250 VDC
• 30 Amp current rating
• NEMA 1 enclosure for indoor use

Product Highlights

This Siemens safety switch is ideal for general duty applications requiring a reliable disconnecting means. It is suitable for 3-phase motor loads and service entrance applications.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: GNF321
• Country of Origin: Mexico

Technical Specifications

• Type: Enclosed/Safety Switch
• Brand: Siemens
• Action: SINGLE THROW
• Voltage: 240 Volt
• Amperage: 30 Amp
• Material: Steel
• Standard: UL
• Enclosure: NEMA1
• Frequency: 60 Hz
• NEMA Size: 1
• Sub Brand: VBII
• Insulated?: No
• Number of Poles: 3 Pole
• Mounting Type: 2 or 3 Point Mounting Holes
• TC Connection: MECHANICALLUGS
• Applications: DISCONNECTINGMEANFORSERVICEENTRANCE/LOADS
• Ambient Temperature: -29 degrees C
• Operating Temperature: -20 To 120 degrees F
• Catalog Number: GNF321
• Manufacturer: Siemens
• Country of Origin: Mexico
• Amperage Rating: 30
• Connection: MECHANICALLUGS
• Mounting: Surface
• Item Type: GENERALDUTYSWITCH
• Voltage Rating AC: 240 volt
• Voltage Rating DC: 250 volt
• Current Rating: 30 amp
• Enclosure Material: Cold Rolled Steel
• Finish: ANSI 61 Gray Painted
• Approval: UL
• Fuse Provision: Non-Fusible
• Application: 3-Phase Motor Load
• Phase: 3
• NEMA: N1
• Protection: Non-Fused
• Maximum Current: 30 A
• Series: GN Series
• Voltage Rating: 240 Vac
