Siemens GLB166.1P Direct Coupled Actuator 24V NSR 88 In-lb Plenum

Product Description

The Siemens GLB166.1P is a direct coupled actuator with an 88 in-lb thrust capacity. This device operates on 24VAC power and is designed for reliable performance in various industrial and commercial applications. The actuator features modulating control with a 0 to 10 VDC output, making it suitable for precise positioning of dampers in HVAC systems.

• Non-spring return design
• Easy-to-see position indicator
• Durable construction for demanding environments

Product Highlights

This actuator is ideal for air handling spaces and supports various applications including HVAC systems, industrial automation, and material handling.

Product Information

Standard Information

• Brand: Siemens Building Technology
• Part Number: GLB166.1P

Technical Specifications

• Power Consumption: 3.3 VA (Modulating), 2.3 VA (Floating)
• Auxiliary Switches: Dual
• Operating Conditions: -25 F To 130 F (-32 C To 55 C)
• Electrical Connection: 3 ft. 18 AWG Plenum Cable
• Housing Rating: NEMA 2, IP54
