Siemens GIB146.1U 3-point non-spring return actuator 24 VAC (90°)

Product Description

Siemens GIB146.1U is a 3-point non-spring return (NSR) electric damper actuator rated for 24 VAC control and 310 lb-in torque. It provides 90° nominal rotation for modulating or three-position control, with manual override, mechanical range adjustment, and a visible position indicator. The actuator includes precabled 18 AWG leads, synchronous motor technology, silicone-free gear lubrication, UL873 and cUL listing, and IP54/NEMA 2 enclosure for HVAC damper applications.

• 310 lb-in torque; 90° nominal (95° maximum) angular rotation; runtime 90 s at 60 Hz and 108 s at 50 Hz for 90°
• 24 VAC operation at 50/60 Hz with precabled 18 AWG leads (3 ft or 6 ft options) and synchronous motor technology
• Manual override, mechanical range adjustment, visible position indicator, silicone-free gear lubrication, UL873 and cUL listed, IP54/NEMA 2

Product Highlights

Electric NSR actuator for HVAC damper control with 310 lb-in torque, 24 VAC operation, 90° rotation, manual override, and IP54/NEMA 2 enclosure.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: GIB146.1U

Technical Specifications

• Brand: Siemens
• MPN: GIB146.1U
• Product type: Electric damper actuator, non-spring return (NSR)
• Series: OpenAir GIB
• Input Voltage: 24 VAC
• Frequency: 50/60 Hz
• Torque: 310 lb-in
• Angle of rotation: 90° nominal, 95° maximum
• Runtime for 90°: 90 s at 60 Hz; 108 s at 50 Hz
• Power consumption: 3.3 VA (modulating); 2.3 VA (three-position)
• Position feedback: No
• Auxiliary switches: 2
• Cable length: Precabled 18 AWG, 3 ft (0.9 m) or 6 ft (1.8 m)
• Shaft dimensions: 3/8 to 5/8 in. (8 to 16 mm) diameter, 3/4 in. (20 mm) minimum length
• Noise level: <35 dBA (running)
• Operating temperature: -22°F to 130°F (-30°C to 55°C)
• Storage temperature: -40°F to 158°F (-40°C to 70°C)
• Ambient humidity: 95% RH (non-condensing)
• Enclosure rating: NEMA 2, IP54 per EN60529
• Housing material: Durable plastic
• Gear lubrication: Silicone-free
• Certifications: UL873 and cUL (C22.2 No. 24-93) listed; CE certified
• Dimensions (W x H x D): 3.94 x 11.81 x 2.69 in
• Weight: 5 lbs
