Siemens GIB146.1P 3PT NSR 24V 310 LB-IN AUX

Product Description

The Siemens GIB146.1P is a non-spring return actuator with a torque rating of 310 lb-in. It operates at twenty-four VAC and is designed for standard control signals. This actuator is part of the OpenAir GIB Series and is suitable for control damper applications.

• Non-spring return functionality
• Torque of 310 lb-in
• Auxiliary switches included

Product Highlights

This electric damper actuator provides reliable performance in heating, ventilation, and air conditioning systems.

Product Information

Standard Information

• Control Type: Control Damper
• Brand: Siemens

Technical Specifications

• Torque: 310 lb-in
• Positioning Time: 50 Hz: 150 seconds, 60 Hz: 125 seconds
• Power Consumption: 2.6 VA/1.8 W
• Ambient Humidity: 95 % r.h.
• Angular Rotation: 90 degrees
• Operating Voltage: 24 VAC
• Frequency: 50/60 Hz
• Auxiliary Switch: 2
• Cable Length: 3 feet
• Dimensions (W x H x D): 3.94 x 11.81 x 2.69 inches
• Housing Material: NEMA 2, die-cast aluminum alloy enclosure, IP54
• Degree of Protection: IP54
