Siemens GIB131.1P Electric Damper Actuator 24V 310 LB-IN PLEN

Product Description

The Siemens GIB131.1P is a robust electric damper actuator designed for precise control over HVAC damper positions. Its 24V operation and 310 lb-in torque capacity make it suitable for a variety of industrial settings.

• Non-spring return mechanism ensures reliable operation
• Includes a plenum cable for straightforward installations
• Features floating control for enhanced modulation

Product Highlights

Constructed with a high-strength metal housing, this actuator is preloaded with 5 degrees from the factory, ensuring immediate functionality upon installation. The model offers a manual override option and is equipped with a clear position indicator for ease of use.

Product Information

Standard Information

• Brand: Siemens
• Model: GIB131.1P

Technical Specifications

• Control Type: 3-position, non-spring return
• Power Source: 24V AC/DC
• Torque: 310 lb-in
• Dimensions: 11.81 x 3.94 x 2.69 inches
• Weight: 5.4 pounds
• Mounting Type: Direct-coupled
• Operational Temperature Range: Standard industrial ranges
