Siemens GGD121.1U Fire And Smoke Actuator, 142 in-lb

Product Description

The Siemens GGD121.1U is a fire and smoke actuator designed for effective operation in various HVAC applications. This actuator features a power ratings of 142 in-lb and operates on 24 VAC/DC. It utilizes a spring return mechanism, ensuring reliable performance for safety applications.

• Reversible fail-safe spring return for both counterclockwise and clockwise rotation.
• Fast operation time of 15 seconds, suitable for quick response needs.
• Patented built-in electronic fusible link enhances safety features.

Product Highlights

The GGD121.1U actuator is engineered for two-position control, providing on/off control signals essential for efficient HVAC systems.

Product Information

Standard Information

• Brand: Siemens
• Part Number: GGD121.1U

Technical Specifications

• Power Consumption: 150 VA Running, 10 VA Holding
• Operating Conditions: 0 F to 130 F (-18 C to 55 C)
• Electrical Connection: 18 AWG Pre-Cabled Connection
• Housing: NEMA 1
