Siemens GF226NRA GDSS FUS 2P3W 240V 600

Product Description

The Siemens GF226NRA is a General Duty Safety Switch. This two-pole, 2-fuse unit is designed for low voltage circuit protection. It features a solid neutral and is housed in a NEMA-3R enclosure suitable for outdoor use. The switch supports up to 600 amperes at 240 volts AC. It is fused to accommodate various horsepower ratings suited for both single-phase and three-phase applications.

• Rated voltage: 240 VAC
• Maximum amperage: 600 A
• Horsepower ratings: 15 hp, 75 hp, 200 hp

Product Highlights

This switch is compliant with service entrance requirements and is suitable for disconnecting means for service entrance and loads including motor loads.

Product Information

Standard Information

• Brand: Siemens
• MPN: GF226NRA

Technical Specifications

• Material: Steel
• Voltage Rating: 240 VAC
• Amperage Rating: 600 A
• Number of Poles: 2
• Enclosure Type: NEMA 3R
• Dimensions: 22.4 in x 6.94 in x 45.32 in
• Weight: 99.803 lb
• Operating Temperature: -29 to 85 degrees C
• Phase: 1/3
• Operating Cycles: 5000
