Siemens GAP191.1P Direct Coupled Actuator, 53 in-lb

Product Description

The Siemens GAP191.1P is a direct coupled actuator designed for efficient modulation and control. It operates on 24 VAC or DC power and offers a torque of 53 in-lb. This actuator is suitable for applications in HVAC systems and is particularly effective in managing air flow in ventilation systems.

• Fail-in-place functionality for fail-safe operation
• Two-position control, floating control, and modulating control options
• Fast operation with a runtime of two seconds

Product Highlights

This actuator provides reliable performance across various HVAC applications. It ensures accurate control of air supply and exhaust in diverse environments.

Product Information

Standard Information

• Brand: Siemens Building Technology
• MPN: GAP191.1P
• Power Consumption: 28 VA running, 8 VA holding
• Operating Conditions: 0°F to 122°F (-18°C to 50°C)

Technical Specifications

• Torque: 53 lb-in
• Electrical Connection: 3 ft. 18 AWG cable
• Feedback: Standard on all models
• Motor Type: Brushless DC motor technology with stall protection
• UL and cUL listed: Yes
• CE certified: Yes
