Siemens ED22B030L Breaker, Molded Case, ED 2P 30A 240VAC 10KA Lugs

Product Description

The SIEMENS ED22B030L is a molded case circuit breaker, ED 2P 30A 240VAC 10KA with Lugs. This Sentron series breaker features a thermal/magnetic trip and is suitable for low voltage applications. It has an interrupt rating of 10kA at 240VAC and is designed for line/load lug connection with wire sizes from 10 to 1/0 AWG.

• RoHS Compliant
• CAD Models

Product Highlights

Molded case circuit breaker with thermal-magnetic trip unit, suitable for various electrical protection applications.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: ED22B030L
• Country of Origin: USA

Technical Specifications

• Brand: SIEMENS
• Current Rating: 30 A
• Frame Type: ED Frame
• Interrupt Rating: 10kA@240VAC kA@400VAC
• Manufacturer Part Number: ED22B030L
• Number of Poles: 2
• Series: Sentron Series
• Type: Thermal/Magnetic
• UPC Code: 783643089778
• Voltage Rating: 240 V
• Voltage: 240 VAC, 125/250 VDC
• Frequency: 50/60 Hz
• Trip Type: Thermal/Magnetic Trip
• Phase: 1 ph
• Connection: Line/Load Lug Connection
• Wire Size: 10 to 1/0 AWG Wire
• Temperature: 40 deg C
