Siemens ED22B015L BRKR ED2 2P 240V 15A

Product Description

The Siemens ED22B015L is a low voltage Sentron molded case circuit breaker with a thermal-magnetic trip unit. This standard 40C breaker features an ED frame with standard breaking capacity. Rated at 15A and 2-pole, it offers 10kAIC at 240V. The non-interchangeable trip unit includes line and load side lugs and a wire range of 14 - 10AWG (CU) / 12 - 10AWG (AL).

• Thermal-magnetic trip unit
• Standard 40C breaker
• ED frame
• Line and load side lugs

Product Highlights

Siemens ED22B015L circuit breaker with thermal-magnetic trip, ED frame, and line/load lugs for reliable performance.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: ED22B015L

Technical Specifications

• Type: ED2
• Brand: Siemens
• Frame: ED2/125A
• Width: 3.000
• Height: 7 Inch
• Length: 6 Inch
• Amperage: 15 Amp
• Sub Brand: Sentron
• Trip Type: Thermal-Magnetic
• Interrupt Rating: 10 kAIC
• Operating Temperature: 40C
• Number of Poles: 2 Pole
• Breaking Capacity: 10KAIC at 240V
• Trip Unit: Non-Interchangeable Thermal-Magnetic
• Frame Type: ED
• Connection Type: Line/Load Lug
• Frequency: 50/60 Hz
• Standard: HACR
• Phase: 1
• Wire Size: 14 to 10 AWG, 12 to 10 AWG
• Application: For standard 40C breaker
• Mounting Type: Panel
• Voltage Rating: 240 VAC, 125/250 VDC
• Frequency Rating: 50/60
• Temperature Rating: 40
