SIEMENS DXR2.M12P-102B Room Automation Station

Product Description

The SIEMENS DXR2.M12P-102B is designed for HVAC systems, offering control and automation for terminal HVAC equipment and Total Room Automation applications. It serves as a central hub integrating lighting, temperature, and shading controls. This unit functions as a BACnet Advanced Application Controller (B-AAC) and is fully programmable.

• Equipped with BACnet/MSTP communications.
• Preconfigured for Variable Air Volume and Constant Volume systems.
• Includes an internal differential pressure sensor.

Product Highlights

This device supports energy optimization while maintaining comfort within spaces.

Product Information

Standard Information

• Brand: SIEMENS
• MPN: DXR2.M12P-102B-CL

Technical Specifications

• Operating Voltage: AC 20.4 to 28.8 V, 24 V
• Frequency: 50/60 Hz
• Power Consumption: 58 VA
• Digital Inputs: 1
• Universal Inputs: 2
• Analog Outputs: 2
• Triac Outputs: 6
• Mounting: Wall mounting, DIN rail
• Communication: BACnet/IP, KNX PL-Link, KNX S-Mode
