Siemens DTLNF213NR Double Throw Safety Switch 100 Amp NEMA 3R

Product Description

Siemens DTLNF213NR is a 100 Amp double throw safety switch designed for load transfer between two power sources. It features a NEMA three R enclosure suitable for outdoor applications. This manual transfer switch provides overload and short circuit protection with a two-pole setup.

• Rated for a voltage of 240 volts.
• Includes a padlockable handle for off position safety.
• UL listed for reliability and safety.

Product Highlights

The Siemens DTLNF213NR is ideal for applications requiring reliable power transfer, meeting both residential and commercial needs.

Product Information

Standard Information

• Manufacturer: Siemens
• Model Number: DTLNF213NR

Technical Specifications

• Voltage Rating: 240 V AC
• Amperage Rating: 100 A
• Number of Poles: 2
• Enclosure Type: NEMA 3R
• Fuse Provision: Non-Fusible
• Operating Temperature Range: -20°F to 120°F
• Power Rating: 15 HP at 240 VAC 1-Phase, 40 HP at 240 VAC 3-Phase
• Approval: UL Listed
