Siemens BQ3B040L Molded Case Circuit Breaker 40 Amp

Product Description

The Siemens BQ3B040L is a 3-Pole common-trip, low voltage molded case circuit breaker (MCCB) designed for circuit protection. Rated at 240V and 40A with an interrupting rating of 10kA, it features line side lugs and load side lugs. It is suitable for electrical distribution and general purpose applications.

• Line side lugs included
• Load side lugs are included
• Thermal/Magnetic Trip

Product Highlights

This Siemens circuit breaker protects against overcurrent, preventing damage to itself and conductors. It is suitable for electrical distribution and general purpose applications.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: BQ3B040L
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: BQ3B040L
• Manufacturer: Siemens
• Brand: Siemens
• Country of Origin: Mexico
• Made in USA: No
• Number of Poles: 3
• Standard: ULLISTED/CSA/NOMCERTIFIED
• UPC: 783643237261
• GTIN: 00783643237261
• Type: BQ Low Voltage
• Poles: 3 Pole
• Voltage: 240 VAC
• Amperage: 40 A
• Mounting Style: Feed-Thru
• Protection: Thermal Magnetic
• Trip Functions: LI - Long-Time and Instantaneous
• Interrupting Rating (AIC): 10 kA
• Wire Size: 16 to 6 AWG, 12 to 6 AWG
• Trip Type: Thermal/Magnetic Trip
• Phase: 3 ph
• Actuator: Handle Actuator
• Connection: Bolt-On/Lug-In/Lug-Out Connection
• Mounting: Panel Mounting
• Temperature: 40 deg C
• Applications: Electrical Distribution
• Connection Type: Bolt-On
• Interrupt Rating: 10 AIC
• TC Connection: BOLT-ON
• Trip Range: Thermal Magnetic
