Siemens BQ2B020H Circuit Breaker 2-Pole 20A 120/240VAC

Product Description

The SIEMENS BQ2B020H is a 2-Pole, 120/240VAC low voltage molded case circuit breaker (MCCB) designed for circuit protection. This general-purpose breaker is a 2-Pole Common-Trip type BQH, rated at 120/240V with an AIR of 22kA. It provides automatic over current protection and can be quickly reactivated after a short circuit. Load side lugs are included.

• 2-Pole Common-Trip circuit breaker type BQH
• Rated 120/240V with an AIR of 22kA
• Load side lugs are included

Product Highlights

The SIEMENS BQ2B020H circuit breaker provides over current protection and allows for quick circuit reactivation. It is calibrated for 40°C maximum ambient application.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: BQ2B020H
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: BQ2B020H
• Manufacturer: Siemens
• Brand: Siemens
• Country of Origin: Mexico
• Actuator Type: Toggle
• Application: Electrical Distribution
• Connection: BOLT-ON
• Interrupt Rating: 22 AIC
• Number of Poles: 2
• Special Features: Finger Safe Terminal Shield
• Standard: UL 489
• UPC Code: 783643161580
• GTIN: 00783643161580
• Series: BQ Series
• Termination: screw
• Current Rating: 20 A
• Voltage Rating: 120/240V
• Trip Range: Thermal Magnetic
