Siemens 8WH90206BS10 Bridge, 20-Pole, For Term Width 5.2 mm

Product Description

The Siemens 8WH90206BS10 is a 20-pole bridge designed for terminal widths of 5.2 mm. This jumper plug is used for cross links in the center of the terminal. It serves as a transverse jumper in the terminal middle, facilitating connections in terminal blocks.

• Designed for cross links in the terminal center
• Suitable for 2.5 sq-mm Terminal, 8WH3 1.5 sq-mm Terminal, 5.2 mm W Spacing ALPHA FIX Terminal Block
• Functions as a transverse jumper in terminal middle

Product Highlights

The Siemens 8WH90206BS10 bridge is a 20-pole connector for 5.2mm terminal blocks, ideal for creating cross links in terminal centers.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 8WH90206BS10
• Country of Origin: DE

Technical Specifications

• Brand: SIEMENS
• Manufacturer Part Number: 8WH90206BS10
• Number of Positions: 20
• UPC Code: 040892563269
• Reference: 8WH90206BS10
• Suitable For Use With: 2.5 sq-mm Terminal, 8WH3 1.5 sq-mm Terminal, 5.2 mm W Spacing ALPHA FIX Terminal Block
• Type: Transverse connector
• Country of Manufacture: DE
• Number of bridged clamps: 20
• Explosion-tested version 'Ex e': No
• Rated current In (A): 24
• Insulated: Yes
• With contact protection: Yes
• Mounting method: Pluggable
• Modular spacing (mm): 5.2
• Colour: Red
• Category: Panel Accessory
