Siemens 8WA1011-1PM00 Feed Through Terminal Block

Product Description

Siemens 8WA1011-1PM00 is a feed through terminal block designed for efficient electrical connections. This terminal is suitable for various applications, particularly in switchboards and distribution boards.

• Space-saving design for incoming and outgoing cables.
• Insulated at both ends with specific types insulated on one side.
• Rated short-time current capability with screw terminals.

Product Highlights

This terminal block is essential for creating organized and safe electrical connections in commercial and industrial settings.

Product Information

Standard Information

• Manufacturer: Siemens
• UPC: 754554380216

Technical Specifications

• Approval: UL, CSA, EAC, GL
• Color: Green/Yellow
• Configuration: Single Tier 1 Circuit
• Construction Standard: IEC
• Housing Material: Thermoplastic
• Mounting: 35 MM DIN Rail
• Temperature Rating: -25 to 55 Deg C
• Terminal Type: Screw Clamp
• Wire Size: 10 to 1 AWG (UL/CSA), 35 Sq MM Solid/Stranded (IEC)
