Siemens 8WA1011-1BF21 Terminal R

Product Description

The SIEMENS 8WA1011-1BF21 is a through screw terminal block of standard construction, featuring a single tier and one circuit. Rated at 800V and 24A, it accommodates wire sizes from 22 to 12 AWG (solid/stranded). The thermoplastic housing ensures durability within a temperature range of -25 to 55 Deg C. It mounts on a 35mm DIN rail.

• REACH/RoHS Compliant
• Screw terminal on both sides
• Thermoplastic housing material

Product Highlights

The SIEMENS 8WA1011-1BF21 terminal block provides a reliable connection with screw terminals and is suitable for various industrial applications.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 8WA1011-1BF21
• Country of Origin: Germany

Technical Specifications

• Voltage: 800 Volt
• Current: 24 Amp
• Mounting Type: DIN Rail 35 Millimeter
• TC Connection: Screw
• Terminal Size: 2.5 mm
• Housing Material: Thermoplastic
• Type: Individual Terminal
• Terminal Block Type: Through-type
• Material: Thermoplastic
• Terminal Type: Screw terminal on both sides
• Configuration: Single terminal
