Siemens 6GK19050FA00 Connector Et200Eco 7/8 inches Male 5/Pk

Product Description

The SIEMENS 6GK19050FA00 connector is part of the SCALANCE series, designed for ET200ECO distributed controllers. This male M12 connector features a 7/8" size, 5 poles, and a single keyway. Constructed with a metal body and an IP65/67 enclosure, it supports solid/stranded cables and includes an axial 180-degree cable outlet.

• Space-saving installation thanks to small, compact design
• Quick commissioning without configuration
• Easy on-site diagnostics via LEDs

Product Highlights

This connector ensures reliable connections in industrial environments, withstanding temperatures from -40 to 70 degrees C.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 6GK19050FA00
• Country of Origin: DE

Technical Specifications

• Brand: SIEMENS
• Manufacturer Part Number: 6GK19050FA00
• Series: 6GK Series
• Keyway Type: Single
• Body Material: Metal
• Current Rating: 9 Amp
• Number Of Poles: 5
• Enclosure: IP65/67
• Type: Male, M12
• Alternate Catalog Number: 6GK1905-0FA00
• Catalog Number: 6GK19050FA00
• Country of Origin: DE
• Standards: RoHS Compliant
• Material: Metal
• Suitable For Use With: ET 200 Series Field Assembly, Male Insert
• Connector Type: Male Ctr
• Angle: Straight
• Connector Mating Size: 7/8 in.-16 UN
• Application/Rating - IEC: IP 65/67
• Additional Info: Operating Temperature: -40 to 70 deg C (-40 to 158 deg F)
• Manufacturer Series: ET200
• Cable Size: 1.5 sq-mm
• Cable Type: Solid/Stranded
• Environmental Conditions: -40 to 70 deg C Operating
• Shell Material: Metal
