Siemens 6ES75221BF000AB0 DQ 8x24VDC/2A

Product Description

The Siemens 6ES75221BF000AB0 is a SIMATIC S7-1500 digital output module DQ 8x24 V DC/2A HF with 8 channels in groups of 8. It features diagnostics and a substitute value. Two channels can be used for pulse width modulation (PWM). The module supports safety-oriented shutdown of load groups up to SIL2 according to EN IEC 62061:2021 and Category 3 / PL d according to EN ISO 13849-1:2015.

• 8, 16 and 32-Channel Digital Output Modules
• For Flexible Adaptation of the Controller to the Corresponding Task
• For Subsequent Expansion of the System with Additional Outputs

Product Highlights

The Siemens 6ES75221BF000AB0 digital output module is designed for use with the SIMATIC S7-1500 Advanced Controller I/O System.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 6ES75221BF000AB0
• Country of Origin: Germany

Technical Specifications

• Number of Inputs: 0
• Application: SIMATIC S7-1500 Advanced Controller I/O System
• Output Type: 8
• Output Configuration: Transistor
• Type: High
• Output Voltage: 24 Volt DC
• Alternate Catalog Number: 6ES7522-1BF00-0AB0
• Amperage Rating: 2 A
• Catalog Number: 6ES75221BF000AB0
• Country of Origin: DE
• Series: S7-1500
• Standards: ISO 13849-1IEC 62061RoHS CompliantREACH Compliant
• Step Response: 80 to 100 us Off to On/300 to 500 us On to Off
• Terminal Type: Push-In/Screw
• UNSPSC: 32151705
• Voltage Rating: 24 VDC
• Brand: Siemens
• Manufacturer: Siemens
• Number of Outputs: 8
• Maximum Output Current per Output: 2 Amp
• Maximum Output Current per Module: 16 Amp
• Backplane Bus Power Rating: 0.9 Watt
• Power Loss: 5.6 Watt
