Siemens 6ES75211BH000AB0 Digital Input Module DI 16X24VDC HF

Product Description

The SIEMENS 6ES75211BH000AB0 is a SIMATIC S7-1500 digital input module DI16 x DC24V with 16 channels in groups of 16. It features an input delay of 0.05 ... 20ms and input type 3 (IEC 61131) diagnosis, processalarms. It is designed for DIN rail mounting and has screw terminals for easy connection.

• 16 digital input channels
• Designed for use with SIMATIC S7-1500 PLCs
• Input delay of 0.05 ... 20ms

Product Highlights

The SIEMENS 6ES75211BH000AB0 digital input module is ideal for industrial automation and control applications requiring reliable digital input signal processing.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 6ES75211BH000AB0
• Country of Origin: Germany

Technical Specifications

• Manufacturer: Siemens
• HQ Catalog Number: 6ES7521-1BH00-0AB0
• Product Family: SIMATIC
• Height (inches): 1.85
• Width (inches): 5.94
• Length (Inches): 5
• Category: Industrial Automation and Controls
• Controllers: PLC Modules
• Number of Inputs and Type: 16 - Digital
• Voltage - Supply: 19.2 ~ 28.8VDC
• Series: SIMATIC S7-1500
• Mounting Type: DIN Rail
• Termination Style: Screw Terminal
• Part Status: Active
• Operating Temperature: -30 C ~ 60 C
• Type: Input Module
• Base Product Number: 6ES75211
• For Use With/Related Products: SIMATIC S7-1500
• Country of Origin: Germany - Subject to change
• Voltage Category: 24 Vdc
• Operating Voltage: 20.4-28.8 Vdc
• Number of Inputs: 16 inputs
• Input Current: 20 mA at 24 Vdc
• Off-State Current: 2.5 mA (max)
• Signal Delay: OFF to ON=0.05 ms to 20 ms, ON to OFF=0.05 ms to 20 ms
• PLC System: Simatic S7-1500
