Siemens 6ES73221FH000AA0 PLC Expansion Module 16 Digital Output 120/230VAC 1A 6ES7322-1FH00-0AA0

Product Description

The Siemens 6ES73221FH000AA0 is a SIMATIC S7-300 digital output module with 16 isolated digital outputs. It operates at 120/230 V AC with a 1 A output. It is designed for use with the S7-300 controller and can be used in a distributed configuration on a PROFINET or PROFIBUS ET 200M interface module.

• 16 Digital Outputs
• Operates at 120/230 V AC
• Maximum Output Current per Output 1 Amp

Product Highlights

The Siemens 6ES73221FH000AA0 digital output module is designed for use with the Simatic S7-300 series.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 6ES73221FH000AA0
• Country of Origin: DE

Technical Specifications

• Alternate Mfr Part Number: 6ES7322-1FH00-0AA0
• Manufacturer: SIEMENS
• For Use With: S7-300 Controller
• Manufacturer Part Number: 6ES73221FH000AA0
• Model Number: SM322
• Number of Outputs: 16
• Output Type: Digital
• Primary Type: Output
• Series: S7-300 Series
• Application: For connecting solenoid valves, contactors, low-power motors, lamps and motor starters and SM 322 series Simatic S7-300 system
• Output Voltage: 120/230 Volt AC
• Maximum Output Current per Output: 1 Amp
• Backplane Output Current: 200 Milliamp at 5 Volt DC
• Power Rating: 8.6 W
• Temperature Rating: -40 to 70 deg C
• Voltage Rating: 120/230 V
• Amperage Rating: 1 A
• Alternate Catalog Number: 6ES7322-1FH00-0AA0
• Connection Cables: 20-pin front connector; shielded/unshielded
• Country of Origin: DE
• Standards: RoHS Compliant
• Sub Brand: SIMATIC
• Terminal Type: 20-Pin Front Connector
• Type: Isolated
