Siemens 6ES72221HH320XB0 Output Module 16 Digital 20.4-28.8V 6ES7222-1HH32-0XB0

Product Description

The SIEMENS 6ES72221HH320XB0 is an output module designed for DIN Rail mounting with a voltage supply of 20.4 ~ 28.8VDC. It is a PLC module from the SIMATIC S7-1200 series, featuring a screw terminal for termination. It has 16 digital outputs and an IP20 Ingress Protection rating.

• DIN Rail mounting
• Operating temperature: -20°C ~ 60°C
• For use with SIMATIC S7-1200

Product Highlights

The SIEMENS 6ES72221HH320XB0 output module is ideal for industrial automation and control applications requiring reliable digital output switching.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 6ES72221HH320XB0
• Country of Origin: DE

Technical Specifications

• Category: Industrial Automation and Controls
• Controllers: PLC Modules
• Voltage - Supply: 20.4 ~ 28.8VDC
• Manufacturer: Siemens
• Mounting Type: DIN Rail
• Series: SIMATIC S7-1200
• Termination Style: Screw Terminal
• Packaging: Box
• Operating Temperature: -20°C ~ 60°C
• Part Status: Active
• Ingress Protection: IP20
• Type: Output Module
• Approval Agency: CE, CSA, cULus, UL
• For Use With/Related Products: SIMATIC S7-1200
• Base Product Number: 6ES72221
• Number of Outputs and Type: 16 - Digital
• Alternate Catalog Number: 6ES7222-1HH32-0XB0
• Amperage Rating: 2 A
• ARRA Compliant: C
• Buy American Compliant: C
• Catalog Number: 6ES72221HH320XB0
• Country of Origin: DE
• Currency: USD
• Dimensions: 100 mm H x 45 mm W x 75 mm D
• EU RoHS Indicator: C
• Gross Volume Per Pack: 32.69
• Gross Volume UOM: in
• Gross Weight Per Pack: 0.5300 lb
• Gross Weight per Pack Metric: 0.24
• Gross Weight UOM Metric: kg
• Harmonization Tariff Schedule Code: 8538903000
• Height: 2.2400 in
• Height [Metric]: 5.6896 cm
• Length: 4.1700 in
• Length [Metric]: 10.5918 cm
• Replaced Catalog Number: 6ES72221HH300XB0
• Returnable: Y
• Standards: CE CertifiedCSA CertifiedUL ListedcULus ListedFM ApprovedRCM ApprovedRoHS Compliant
• Step Response: 10 ms Off to On/On to Off
• Temperature Rating: -20 to 60 °C
• Terminal Type: Front Connector
• UNSPSC: 32151705
• UPC 11: 88762121769
• UPC 12: 887621217693
• Voltage Rating: 24 VDC
• Width: 3.5000 in
• Width [Metric]: 8.8900 cm
• Stock Status: NORMALLY STOCKED
• Brand: Siemens
• Number of Outputs: 16
• Model: 6ES7222-1HH32-OXBO
• MPN: 6ES7222-1HH32-0XB0
• Controller Platform: S7/1200
• UPC: Does not apply
