Siemens 6ES71936BP200BF0 Connector Module

Product Description

The SIEMENS 6ES71936BP200BF0 is a connector module designed for use with the SIMATIC S7-1200 series of programmable logic controllers. This component provides reliable signal and power interconnection between PLC modules and field devices in industrial automation systems. Weighing 0.126 pounds and measuring 4.803 inches by 1.772 inches by 1.102 inches, it is a compact unit suited to panel and cabinet installations. Licensed automation technicians and industrial electricians typically specify this connector when assembling or servicing S7-1200 control architectures.

This connector module is used in industrial control panels, machine automation cabinets, and process control environments where S7-1200 PLC modules require structured wiring termination. It is packaged one per pack, making it a direct single-unit replacement or add-on component for existing S7-1200 installations in both light industrial and heavy manufacturing applications.

Key Features

• Compact form factor: 4.803 inches x 1.772 inches x 1.102 inches for space-constrained panel mounting
• Lightweight construction at 0.126 pounds for easy handling during installation
• Designed for structured wiring termination in S7-1200 PLC systems
• Single-unit pack for direct replacement or incremental system expansion

Compatibility

Designed as an OEM-style connector module for use with SIMATIC S7-1200 series programmable logic controller systems.

Installation Notes

Installation should be performed by a qualified automation technician or licensed electrician in accordance with applicable NEC guidelines and the system manufacturer's wiring documentation. Always de-energize and lock out the control panel before removing or installing PLC connector modules. Verify module seating and wiring termination integrity before restoring power to the system. Do not force the connector into position, as improper seating can damage PLC backplane contacts.

Technical Specifications

• Length: 4.803 inches
• Width: 1.772 inches
• Height: 1.102 inches
• Weight: 0.126 pounds
• Quantity per Pack: 1
• UPC: 88762178280

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 6ES71936BP200BF0
