Siemens 6ES71936AF000AA0 Simatic Et 200 Shield Connector

Product Description

The SIEMENS 6ES71936AF000AA0 is a shield connector designed for use with the SIMATIC ET 200 distributed I/O system. Shield connectors provide a reliable termination point for cable shielding, helping to maintain signal integrity and reduce electromagnetic interference in industrial control and automation installations. This component is installed by qualified automation technicians and control system integrators working with Siemens distributed I/O hardware. At 0.139 pounds and compact dimensions of 3.031 inches x 2.559 inches x 0.906 inches, it is sized for standard ET 200 module rail mounting.

This shield connector is suited for industrial automation environments where shielded cable management is required at the I/O level. It is typically installed in control panels, machine enclosures, and distributed I/O stations running SIMATIC ET 200 series hardware. The part ships in a pack of one and is appropriate for new builds and field replacements requiring proper EMC shielding practice.

Key Features

• Provides secure cable shield termination for SIMATIC ET 200 distributed I/O systems
• Compact form factor at 3.031 inches x 2.559 inches x 0.906 inches for panel-dense installations
• Lightweight at 0.139 pounds for easy handling during installation
• Supports EMC compliance by grounding cable shields at the I/O terminal level
• Sold as one unit per pack

Compatibility

Designed for use with the Siemens SIMATIC ET 200 distributed I/O system family as a shield connector termination component.

Installation Notes

Installation should be performed by a qualified automation or controls technician familiar with Siemens SIMATIC hardware. De-energize the control system and follow applicable lockout/tagout procedures before servicing any I/O module or connector. Ensure cable shields are properly terminated per the system wiring documentation to maintain EMC integrity. Refer to the relevant Siemens SIMATIC ET 200 system manual for mounting and grounding guidance.

Technical Specifications

• Weight: 0.139 pounds
• Length: 3.031 inches
• Width: 2.559 inches
• Height: 0.906 inches
• Pack Quantity: 1
• UPC: 88762108697

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 6ES71936AF000AA0
