Siemens 6ES71384FR000AA0 ET200S, 1 F-RO

Product Description

The SIEMENS 6ES71384FR000AA0 ET200S is a 30 mm wide electronic module with 1 relay output (2 NO-contacts). It features an output current of 5A and rated voltage of 24V DC and 24 ... 230V AC. It is usable up to Cat.4 / SIL 3 if controlled by a F-DO (e.g. 6ES7138-4FB02-0AB0).

• 30 mm width
• Output current 5A
• Rated voltage 24V DC and 24 ... 230V AC

Product Highlights

The SIEMENS 6ES71384FR000AA0 ET200S electronic module is designed for use with SIMATIC DP systems, providing a reliable relay output for various automation applications.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 6ES71384FR000AA0
• Country of Origin: Germany

Technical Specifications

• Amperage: 5 Amp
• Number of Inputs: 0
• Output: (1) Relay
• Power Consumption: 2.1 W
• Voltage: 24 VDC, 24-230 VAC
• Brand: Siemens
• Sub Brand: Simatic
• Lifecycle Status: Obsolete
• Introduction Date: 2017-10-11
• LTB Date: 2023-10-01
• Environmental Classification: RoHS Compliant
• Alternate Catalog Number: 6ES7138-4FR00-0AA0
• Amperage Rating: 5 A
• Catalog Number: 6ES71384FR000AA0
• Country of Origin: DE
• EU RoHS Indicator: C
• Harmonization Tariff Schedule Code: 8538903000
• Number of Outputs: 1
• Voltage Rating: 24 to 230 VAC, 24 VDC
• Manufacturer: Siemens
• Manufacturer Part Number: 6ES71384FR000AA0
• Unit of Measure: EA
