Siemens 6ES71366BA010CA0 I/O Module 8 Digital 24V (15 mm) 3473-6ES71366BA010CA0-ND

Product Description

The Siemens 6ES71366BA010CA0 is a SIMATIC ET 200SP I/O module providing eight digital inputs and eight digital outputs with a 24 V DC supply. It mounts to the ET 200SP backplane, uses spring terminal termination, and has IP20 ingress protection with an operating temperature range of 0 to 60 C. The compact 15 mm module supports high forward diagnostics and safety ratings up to PLe and SIL3.

• Eight digital inputs and eight digital outputs for 24 V DC systems
• Backplane mounting for SIMATIC ET 200SP with spring terminal termination and IP20 protection
• Compact 15 mm width, high forward diagnostics (HF), safety capable to PLe (ISO 13849-1) and SIL3 (IEC 61508)

Product Highlights

8 DI / 8 DO ET 200SP I/O module, 24 V DC, 15 mm width, IP20, PLe/SIL3

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 6ES71366BA010CA0

Technical Specifications

• Brand: Siemens
• Manufacturer Part Number: 6ES71366BA010CA0
• Base Product Number: 6ES71366
• Series: SIMATIC ET 200SP
• Type: I/O module (digital)
• Number of Inputs: 8 digital
• Number of Outputs: 8 digital
• Input Voltage: 24 V DC
• Mounting Type: Backplane
• Termination Style: Spring terminal
• Ingress Protection: IP20
• Operating Temperature: 0 to 60 C
• Dimensions: 73 mm H x 15 mm W x 58 mm D
• Width: 15 mm
• Diagnostics: High forward (HF) diagnostics
• Safety Ratings: PLe (ISO 13849-1); SIL3 (IEC 61508)
• RoHS Status: ROHS3 compliant
• Moisture Sensitivity Level: MSL 1 (Unlimited)
• Part Status: Active
• Category: Industrial Automation and Controls
• For Use With: ET 200SP series
• Distributor Part Number: 3473-6ES71366BA010CA0-ND
• UPC: 195125259973
