Siemens 6es71314fb000ab0 Digital Input Module 230V Ac

Product Description

The SIEMENS 6es71314fb000ab0 is a 2-channel digital input module designed for use with the SIMATIC ET 200S distributed I/O system. It accepts 230V AC input signals and occupies a 15 mm slot width on the ET 200S rail, making it a compact option for panel builders and system integrators working with high-voltage AC field devices. The module uses screw or spring clamp connections for field wiring and is packaged in units of 5. Installation and commissioning are typically handled by licensed industrial electricians or automation technicians familiar with SIMATIC DP network architecture.

This module is suited for industrial automation applications where 230V AC discrete signals must be read into a PROFIBUS DP or PROFINET-based control system via the ET 200S platform. Typical installations include machine control panels, process automation cabinets, and distributed field I/O assemblies in manufacturing environments. The 15 mm wide form factor allows dense module packing on the ET 200S power bus rail. Packaging comes in units of 5 modules, appropriate for multi-station builds or spare-parts stocking.

Key Features

• 2 discrete digital inputs rated for 230V AC signals
• 15 mm slot width for compact ET 200S rail installation
• Screw or spring clamp connection options for field wiring flexibility
• Packaged in units of 5 per packaging unit
• Compatible with SIMATIC ET 200S electronic module system

Compatibility

Designed for use with SIMATIC ET 200S distributed I/O systems using electronic module slots. Compatible with the ET 200S DP and PN station configurations that support 2 DI 230V AC electronic modules.

Installation Notes

Installation should be performed by a qualified industrial electrician or automation technician familiar with SIMATIC ET 200S hardware. De-energize the ET 200S station and isolate all 230V AC field circuits before handling modules. Modules must be seated fully on the terminal module before applying power. Consult the applicable system wiring diagrams and local electrical codes before connecting high-voltage AC field devices.

Technical Specifications

• Number of Inputs: 2
• Input Voltage: 230V AC
• Module Width: 15 mm
• Connection Type: Screw or Spring Clamp
• Height: 2.37 inches
• Length: 3.55 inches
• Width: 3.15 inches
• Depth: 52 mm
• Weight: 0.384 pounds
• Packaging Unit Quantity: 5 pieces
• Country of Origin: China

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 6es71314fb000ab0
