Siemens 61449 MARS 3 Pole 40 Amps 480VAC Coil Definite Purpose Contactor

Product Description

The Siemens 61449 is a 3-pole definite purpose contactor ideal for refrigeration, air conditioning, and electric heating systems. This product features an enclosed body that offers quieter operation and contributes to an extended lifespan. The oversized arch window simplifies wiring, while high-performance copper and brass conductors enhance current carrying capability. The design also includes multi-purpose coil terminals suitable for quick connect terminals or stripped wires, removable coils for easy field replacement, and a cover that can be removed to access the contacts easily.

• Designed for refrigeration, air conditioning, and electric heating systems
• Enclosed body provides quieter running and longer life
• High-performance copper and brass conductors maximize current carrying capability

Product Highlights

The Siemens 61449 contactor is built for reliability with a robust design tailored for demanding environments.

Product Information

Standard Information

• Brand: Siemens
• MPN: 61449

Technical Specifications

• Contactor Type: Definite Purpose
• No. of Poles: 3
• FLA Inductive: 40
• FLA Resistive: 50
• Coil Voltage: 480VAC
• Coil Hz: 50/60
• Lug or Screw Terminal: Box Lug/Dual QC
• Standards: UL
• No. of QC Terminals Per Pole: 2
